Blunt probe

Used to capture and verify checkpoints and capture patient landmarks (green).

Knee tibial array

Used to track the position and orientation of the tibia bone. Attaches to the array adapter and used in combination with the bone clamp and bone pins to securely fix to the tibia bone.

Array stabilizer (3.2 or 4.0 short)

Used as a guide for tibia bone pin insertion. Remains in place during the procedure to provide stability to the tibia array assembly. Available for 3.2 mm and 4.0 mm diameter bone pins.

Registration tool

Attaches to the MICS handpiece and is used for registration of the robotic-arm.

Square driver

Used to tighten/loosen the square-head screws of the MICS handpiece, 2-pin clamps, pelvic array adaptors, and bone arrays.

Planar probe

Used for bone resection depth and angular error measurement.

Lamina spreader

Forced-based spreader with force graduations used in combination with the knee tensioner to provide joint distraction.

Sagittal saw attachment

Attaches to the MICS handpiece and a saw blade. Used to make planar bone resections for the femur anterior, femur anterior chamfer, femur posterior, and proximal tibia.

Angle saw attachment

Attaches to the MICS handpiece and a saw blade. Used to make planar bone resections for the femur distal and femur posterior chamfer.
